Geberit 90mm Shower Tray Trap & Waste - Chrome
Couldn't load pickup availability
The Geberit 90mm Shower Tray Trap and Waste in Gloss Chrome is a practical drainage solution designed for compatible shower trays with a 90mm waste aperture. Its modern, round design provides a neat finish, while the chrome drain cover complements contemporary bathroom fittings. Suitable for shower trays without an overflow, this Geberit shower waste can also be used as a floor drain with a horizontal outlet. The integrated trap provides a 50mm water seal, helping maintain the intended drainage arrangement. Designed with accessible internal components, the waste combines functional drainage with straightforward maintenance, making it a useful choice for bathroom installations requiring a reliable and easy-to-clean shower tray waste assembly.
Designed for convenient installation and servicing, the Geberit shower tray waste features a removable trap cup and a dismantlable dip tube, allowing components to be accessed for cleaning. The supplied components include the drain cover, Trap Comb insert, fastening material, an adaptor for connecting a 40mm outlet to a G 1 1/2-inch connection with a 43mm diameter, and a straight PE-HD connector. The product is quality-monitored in accordance with EN 274-3. Before installation, check that the shower tray has the required 90mm valve opening and does not have an overflow. The horizontal outlet arrangement also allows use as a floor drain where suitable. Images are for illustration purposes only.
PRODUCT SPECIFICATION
- Product Type: Shower Tray Trap and Waste
- Brand: Geberit
- Finish: Gloss Chrome
- Width: 90mm
- Style: Modern
- Shape: Round
- Mounting: Deck
- Water Seal Depth: 50mm
- Required Shower Tray Valve Hole Diameter: 90mm
- Outlet Type: Horizontal
- Connector Adaptor: 40mm to G 1 1/2-inch (43mm diameter)
- Connector Material: PE-HD
- Standard: Quality-monitored in accordance with EN 274-3
PRODUCT FEATURES
- Suitable for shower trays without an overflow
- Can be used as a floor drain with a horizontal outlet
- Removable trap cup for easier cleaning and maintenance
- Dismantlable dip tube
- Supplied with a drain cover and Trap Comb insert
- Fastening material included
- Includes an adaptor for connecting the waste outlet to the specified pipe connection
- Includes a straight PE-HD connector
- Designed for straightforward installation and use
- Images are for illustration purposes only
