Geberit Alpha Concealed Cistern with Square Chrome Flush Plate for 820mm Hieight
Couldn't load pickup availability
The Geberit Alpha Concealed Cistern with Square Chrome Flush Plate is a modern bathroom installation solution designed to complement contemporary toilet spaces. Combining a concealed plastic cistern with a stylish square-button flush plate in gloss chrome, it provides a neat, streamlined appearance by keeping the cistern hidden from view. The rectangular cistern measures 395mm high and 440mm wide, with an installation height of 820mm to suit the specified bathroom configuration. Finished in white, the cistern is designed for concealed mounting and features insulation to help prevent condensation. Supplied as part of the Geberit Alpha collection, this practical combination offers a coordinated flushing solution backed by a 10-year guarantee.
Designed for installation against masonry walls and within part-height prewall installations, the Geberit Alpha cistern is suitable for floor-standing and wall-hung WCs. Its adjustable depth helps accommodate installation requirements, while top or front actuation provides flexibility when positioning the flush plate. The dual-flush mechanism supports water-saving operation, with factory flush volumes of 5.8 litres for a full flush and 3 litres for a reduced flush. The cistern also allows adjustment of both flush volumes and supports immediate post-flushing with the factory setting. A welded flush bend and a service-opening protection box, which can be cut to length, are included as design features. Images are for illustration purposes only.
PRODUCT SPECIFICATION
- Product Type: Concealed Cistern and Flush Plate
- Brand: Geberit
- Collection: Alpha
- Finish: White cistern with gloss chrome flush plate
- Height: 395mm
- Width: 440mm
- Installation Height: 820mm
- Depth: 120mm
- Style: Modern
- Shape: Rectangular cistern with square flush buttons
- Mounting: Concealed
- Material: Plastic
- Guarantee: 10 Years
- Flow Pressure: 0.1–10 bar
- Maximum Water Temperature: 25°C
- Factory Flush Volume: 5.8 / 3 litres
- Full Flush Volume Adjustment Range: 4 / 4.5 / 6 / 7.5 litres
- Small Flush Volume Adjustment Range: 2–4 litres
- Flush Plate Button Shape: Square
- Flush Actuation: Top or front
PRODUCT FEATURES
- Gloss chrome square flush plate included
- Suitable for masonry walls and part-height prewall installations
- Compatible with floor-standing and wall-hung WCs
- Adjustable depth for installation flexibility
- Fully insulated against condensation
- Dual-flush operation
- Immediate post-flush possible with factory setting
- Welded flush bend
- Water supply connection positioned on the left or rear left
- Service-opening protection box can be cut to length to help protect against moisture and dirt
- Cistern complies with EN 14055, Class II requirements
- Designed for easy installation and use
- Images are for illustration purposes only
